I find dhcp server assigned IP address to MAC.but It didn’t found operatingsystem.
The foreman-proxy.log:
2022-02-11T20:33:47 087e76cb [I] Started POST /tftp/PXEGrub/00:0c:29:d8:b9:a0
2022-02-11T20:33:47 087e76cb [I] Finished POST /tftp/PXEGrub/00:0c:29:d8:b9:a0 with 200 (2.12 ms)
2022-02-11T20:33:47 087e76cb [I] Started POST /tftp/iPXE/00:0c:29:d8:b9:a0
2022-02-11T20:33:47 087e76cb [I] Finished POST /tftp/iPXE/00:0c:29:d8:b9:a0 with 200 (1.37 ms)
2022-02-11T20:33:47 087e76cb [I] Started POST /tftp/fetch_boot_file
2022-02-11T20:33:47 087e76cb [I] Finished POST /tftp/fetch_boot_file with 200 (5.34 ms)
2022-02-11T20:33:47 087e76cb [I] [10343] Started task [“/usr/bin/wget”, “–connect-timeout=10”, “–dns-timeout=10”, “–read-timeout=60”, “–tries=3”, “-nv”, “-c”, “http://172.16.10.166:800/windows/2016////wimboot”, “-O”, “/var/lib/tftpboot/boot/windows-x86_64-windows10-SeRA8q364mKv/wimboot”]
2022-02-11T20:33:47 087e76cb [I] Started POST /tftp/fetch_boot_file
2022-02-11T20:33:47 087e76cb [I] Finished POST /tftp/fetch_boot_file with 200 (1.59 ms)
2022-02-11T20:33:47 087e76cb [I] [10346] Started task [“/usr/bin/wget”, “–connect-timeout=10”, “–dns-timeout=10”, “–read-timeout=60”, “–tries=3”, “-nv”, “-c”, “http://172.16.10.166:800/windows/2016////bootmgr”, “-O”, “/var/lib/tftpboot/boot/windows-x86_64-windows10-SeRA8q364mKv/bootmgr”]
2022-02-11T20:33:47 087e76cb [I] Started POST /tftp/fetch_boot_file
2022-02-11T20:33:47 087e76cb [I] Finished POST /tftp/fetch_boot_file with 200 (1.55 ms)
2022-02-11T20:33:47 087e76cb [I] [10349] Started task [“/usr/bin/wget”, “–connect-timeout=10”, “–dns-timeout=10”, “–read-timeout=60”, “–tries=3”, “-nv”, “-c”, “http://172.16.10.166:800/windows/2016///boot/bcd”, “-O”, “/var/lib/tftpboot/boot/windows-x86_64-windows10-SeRA8q364mKv/bcd”]
2022-02-11T20:33:47 087e76cb [I] Started POST /tftp/fetch_boot_file
2022-02-11T20:33:47 087e76cb [I] Finished POST /tftp/fetch_boot_file with 200 (1.86 ms)
2022-02-11T20:33:47 087e76cb [I] [10351] Started task [“/usr/bin/wget”, “–connect-timeout=10”, “–dns-timeout=10”, “–read-timeout=60”, “–tries=3”, “-nv”, “-c”, “http://172.16.10.166:800/windows/2016///boot/boot.sdi”, “-O”, “/var/lib/tftpboot/boot/windows-x86_64-windows10-SeRA8q364mKv/boot.sdi”]
2022-02-11T20:33:47 087e76cb [I] Started POST /tftp/fetch_boot_file
2022-02-11T20:33:47 087e76cb [I] Finished POST /tftp/fetch_boot_file with 200 (0.98 ms)
2022-02-11T20:33:47 087e76cb [I] [10352] Started task [“/usr/bin/wget”, “–connect-timeout=10”, “–dns-timeout=10”, “–read-timeout=60”, “–tries=3”, “-nv”, “-c”, “http://172.16.10.166:800/windows/2016///sources/boot.wim”, “-O”, “/var/lib/tftpboot/boot/windows-x86_64-windows10-SeRA8q364mKv/boot.wim”]
2022-02-11T20:33:47 087e76cb [I] Started DELETE /puppet/ca/autosign/windows.dd.com
2022-02-11T20:33:47 087e76cb [E] Attempt to remove nonexistent client autosign for windows.dd.com
2022-02-11T20:33:47 087e76cb [W] Error details for Attempt to remove nonexistent client autosign for windows.dd.com: : Attempt to remove nonexistent client autosign for windows.dd.com
2022-02-11T20:33:47 087e76cb [W] Attempt to remove nonexistent client autosign for windows.dd.com: : Attempt to remove nonexistent client autosign for windows.dd.com
2022-02-11T20:33:47 087e76cb [I] Finished DELETE /puppet/ca/autosign/windows.dd.com with 404 (3.24 ms)
2022-02-11T20:33:47 087e76cb [I] Started DELETE /puppet/ca/windows.dd.com
2022-02-11T20:33:49 087e76cb [I] Finished DELETE /puppet/ca/windows.dd.com with 200 (1784.51 ms)
2022-02-11T20:33:49 087e76cb [I] Started POST /puppet/ca/autosign/windows.dd.com
