I’m playing around with Katello 4.2, using Openshift 4.8(crc) to scrape the metrics using the ServiceMonitor to get the data outside of the Openshift Cluster.
The ServiceMonitor is one extension of the Prometheus API, that is created in the a Kubenertes/Openshift cluster when Prometheus is deployed using it’s own Operator.
My main goal was to use the APIs that we already have in Openshift, no one want to manage one stand-alone cluster of Prometheus.
If you have a local Openshift cluster to test, here are the steps that I followed:
Prerequisites:
Both Katello/Foreman and Openshift needs to see each other in the network, at least the /metrics endpoint.
One user with cluster-admin permission in Openshift or with the right granular permission to create one ServiceMonitor Object in one namespace.
I’m assuming that the Katello/Foreman node is already running the telemetry plugin.
- Enable[1] the monitoring for User Defined Projects in Openshift:
apiVersion: v1
kind: ConfigMap
metadata:
name: cluster-monitoring-config
namespace: openshift-monitoring
data:
config.yaml: |
enableUserWorkload: true
oc create -f cluster-monitoring-user-config.yaml
This will create a new namespace, that will monitor the API for ServiceMonitor objects
oc get pods -n openshift-user-workload-monitoring
- Create the new namespace and the Network Objects that will map the Katello/Foreman IP to Openshift.
oc new-project foreman-monitor
To map the external IP to this cluster we will use a Service with ClusterIP that will be pointing to one Endpoint object that will have the Foreman/Katello IP.
kind: Service
apiVersion: v1
metadata:
name: foreman-prometheus
labels:
external-service-monitor: "true"
spec:
type: ClusterIP
ports:
- name: web
port: 80
targetPort: 80
oc create -f svc.yaml
Note that this service don’t have any Label defined as source.
For this service to be valid, we need to create one Endpoint that I’ll point to Foreman/katello IP.
kind: Endpoints
apiVersion: v1
metadata:
name: foreman-prometheus
subsets:
- addresses:
- ip: 192.168.122.119
ports:
- name: web
port: 80
Note that 192.168.122.119 is the IP from my Katello installation, change to match yours.
oc create -f endpoint.yaml
We can validate if the endpoint is working with a service description:
oc describe svc
Name: foreman-prometheus
Namespace: foreman-monitor
Labels: external-service-monitor=true
Annotations: <none>
Selector: <none>
Type: ClusterIP
IP Family Policy: SingleStack
IP Families: IPv4
IP: 10.217.4.200
IPs: 10.217.4.200
Port: web 80/TCP
TargetPort: 80/TCP
Endpoints: 192.168.122.119:80 <<<<<<<<<<<<<< The Endpoint is working
Session Affinity: None
Events: <none>
- The only thing left is to create the serviceMonitor object inside of the foreman-monitor namespace:
apiVersion: monitoring.coreos.com/v1
kind: ServiceMonitor
metadata:
name: foreman-prometheus
namespace: foreman-monitor
spec:
endpoints:
- port: web
interval: 30s
scheme: http
path: /metrics
selector:
matchLabels:
external-service-monitor: "true"
oc create -f servicemonitor.yaml
This serviceMonitor Object will look for the one object with the label external-service-monitor
as true
, and will scrape the /metrics.
After a couple minutes, the httpd log will start to show entry’s like this one:
"GET /metrics HTTP/1.1" 200 3700 "-" "Prometheus/2.26.1"
To view the metrics we can to Monitoring > Metrics > add the following metric fm_rails_http_requests
and press Run Queries.
I’m yet to reach the Grafana side of Prometheus inside of Openshift.
1 - Enabling monitoring for user-defined projects | Monitoring | OpenShift Container Platform 4.8
